Home » More » UPS & Power » UPS Accessories » Lenovo AP7822B

[AP7822B] Lenovo Rack PDU Metered 2U 32A 230V (12) C13 (4) C19

Lenovo Rack PDU Metered 2U 32A 230V (12) C13 (4) C19 Click image for larger image.

Product may vary from image. Rely only on description for purchasing decisions.
shadow
Our Price:
$1,432.78
(Inc. GST)
Availability:

Est. Delivery:
1-3 days
Brand:
Man. Part #:
AP7822B
Our Part #:
AP7822B
Calculate Delivery Cost
Postcode:
Please enter a postcode to caculate shipping prices.
shadow
Product Quantity:
Print this Page Ask Us About AP7822B Price Match AP7822B
APC AP7822B, Metered, 2U, Single-phase, Horizontal/Vertical, Black, 16 AC outlet(s)

Resettable circuit breakers
Enables a quick recovery from overload events.

Load indicator LED
Indicates overload and warning conditions based on the user-defined alarm thresholds. Alerts users of potential overloaded circuits.

Alarm Thresholds
Define alarm thresholds in order to avoid overloaded circuits. Network and visual alarms inform the user of possible problems. (Note: Only available on units with the current monitoring capabilities. Please see SKU specifications for availability)

Flash Upgradeable
Quickly and easily upgrade firmware via network download for future product enhancements. Eliminates the need to replace products already installed in the field when new features are released. (Note: Networked units only)

Integrates with StruxureWare Data Center Expert
An IT-ready, scalable access monitoring system that collects, organizes, and distributes critical alerts, surveillance video and key information, providing a unified view of complex physical infrastructure environments from anywhere on the network

Local Current Monitoring Display
The aggregate current draw per rack PDU is displayed on the unit via a digital display. The local digital display helps installers avoid overloaded circuits by providing a visible warning when the current draw is close to the maximum amperage draw of the strip. (Available on designated SKUs only)

Remote Management Capabilities
Full-featured network management interfaces that provide standards-based management via Web, SNMP, and Telnet. Allows users to access, configure, and manage units from remote locations to save valuable time. Associated with this feature is the ability to quickly and easily upgrade the firmware via network download to installed units for future product enhancements.
Design
PDU types
A power distribution unit (PDU) is a device fitted with multiple outputs designed to distribute electric power, especially to racks of computers and networking equipment located within the data center. PDUs vary from simple and inexpensive rack-mounted "power strips" to larger floor-mounted PDUs with multiple functions including power filtering to improve power quality, intelligent load balancing, and remote monitoring and control by LAN or SNMP.
Metered
Type
Characteristics of the device.
Single-phase
Rack capacity
The spase that device fill in rack.
2U
Mounting
What size the mounting head of the product is, to couple it with a camera.
Horizontal/Vertical
Product colour
The colour e.g. red, blue, green, black, white.
Black
On/off switch
The button which is pressed to switch the device on or off.
Y
Ports & interfaces
AC outlets quantity
The number of sockets in the device where AC electrical power can be connected.
16 AC outlet(s)
Power plug
A power plug is a 2 or 3 pinned device that is placed into an electrical socket in order to make an electrical connection.
IEC309
AC outlet types
The type of outlet for AC electricity.
C13 coupler, C19 coupler
Input connection type
The type of connection /port for the input(s) into this device e.g. USB.
IEC 309 32A 2P+E
Output connections
12 x C13 4 x C19
Features
LED indicators
Y
Cable length
How long the cable is.
3.66 m
Certification
C-tick, CE, FCC 15 A, GOST, ICES-003, IRAM, MIC, VDE, VCCI
Management features
Monitoring
Current, Power, Voltage
Power
Nominal input voltage
The voltage which the manufacturer recommends that the device needs to operate normally.
208-230 V
AC input frequency
50 - 60 Hz
Maximum current
The greatest possible amount of current, which is a quantity representing the rate of flow of electric charge.
32 A
Load capacity
7680 VA
Maximum input current per phase
32 A
Maximum total current draw per phase
32 A
Power protection features
Features that protect the device against power problems e.g. overload.
Overload
Maximum power
The maximum power that can be put into or produced by the device.
7680 W
Weight & dimensions
Dimensions (WxDxH)
Dimensions of the product (Width x Depth x Height).
444 x 112 x 88 mm
Weight
Weight of the product without packaging (net weight). If possible, the net weight is given including standard accessories and supplies. Please note that sometimes the manufacturer leaves out the weight of accessories and/or supplies.
3.36 kg
Packaging data
Package dimensions (WxDxH)
508 x 368 x 140 mm
Package weight
Weight of the packaged product.
5.41 kg
Operational conditions
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
-5 - 45 °C
Storage temperature (T-T)
The minimum and maximum temperatures at which the product can be safely stored.
-25 - 65 °C
Operating relative humidity (H-H)
5 - 95%
Storage relative humidity (H-H)
5 - 95%
Technical details
Sustainability certificates
RoHS
