Home » Networking » Wireless Access Points » TP-Link CPE220

[CPE220] TP-Link Outdoor 2.4GHz 300Mbps Wireless CPE, Qualcomm, up to 30dBm, 2T2R, 2.4GHz 802.11b/g/n, 12dBi directional antenna, 2 10/100Mbps LAN, Weather proof, Passiv

TP-Link Outdoor 2.4GHz 300Mbps Wireless CPE Qualcomm up to 30dBm 2T2R 2.4GHz 802.11b/g/n 12dBi directional antenna 2 10/100Mbps LAN Weather proof Passiv Click image for larger image.

Product may vary from image. Rely only on description for purchasing decisions.
shadow
Our Price:
$89.00
(Inc. GST)
Availability:

Est. Delivery:
Brand:
Man. Part #:
CPE220
Our Part #:
CPE220
Calculate Delivery Cost
Postcode:
Please enter a postcode to caculate shipping prices.
shadow
Product Quantity:
Print this Page Ask Us About CPE220 Price Match CPE220
TP-LINK CPE220, 300 Mbit/s, 300 Mbit/s, 2.4 - 2.483 GHz, 2.4 GHz, IEEE 802.11b,IEEE 802.11g,IEEE 802.11n, 5 channels

TP-LINK’s 2.4GHz 300Mbps 12dBi Outdoor CPE, the CPE220 is dedicated to cost effective solutions for outdoor wireless networking applications. With its centralized management application, it is flexible and ideal for point-to-point, point-to-multipoint and outdoor Wi-Fi coverage applications. Professional performance, coupled with user-friendly design, makes CPE220 an ideal choice for both business and home users.

Enterprise Hardware
With Qualcomm Atheros enterprise level chipsets, high gain antennas and high quality material, specially designed enclosure, and PoE power supply, CPE220 is specially designed for outdoor use and can operate flawlessly in almost any climate, with operating temperatures ranging from -30? (-22?) to +70 ? (158?).

Advanced Antenna System
- Built-in High Gain Dual-Polarized Antenna
- Dedicated metal reflector ensures higher gain and lower noise interference

13km+ Wireless Data Transmission
Specially designed for outdoor uses, ideal for long distance wireless data transmission over 13km+, tested in the field.

TP-LINK MAXtream TDMA Technology

As network scale increases, wireless competition and collisions among CPEs and base stations will be so enormous that the real throughput of the network will drop, resulting in a serious impact on end-user experience. To mitigate these effects, the CPE220 uses MAXtream TDMA Technology.

Pharos Control – Centralized Management System

CPE220 also comes equipped with centralized management software that helps users easily manage all the devices in their network from a single PC - Pharos Control. Functions like device discovery, status monitoring, firmware upgrading, and network maintenance can be managed using Pharos Control.

PharOS

User-friendly web-based management system allows professionals to do more specific configurations.
Features
2.4 GHz
Y
5 GHz
N
Maximum data transfer rate
The maximum speed with which data can be transmitted from one device to another.
300 Mbit/s
Wi-Fi data rate (max)
300 Mbit/s
Frequency band
A small section of the spectrum of radio communication frequencies, in which channels are usually used or set aside for the same purpose e.g.for a channel on FM radio; for mobile networks to communicate with mobile phones.
2.4 - 2.483 GHz
Bandwidth
2.4 GHz
Networking standards
The way in which the network is working, e.g. IEEE 802.11a, IEEE 802.11b, IEEE 802.11g.
IEEE 802.11b,IEEE 802.11g,IEEE 802.11n
Channels quantity
The number of channels the device has. There can be an individual input or output for each channel.
5 channels
Channel bandwidth
40 MHz
Automatic channel selection
Y
VLAN support
A Virtual Local Area Network (VLAN) consists of a group of computers and switches that can be physically distributed over different networks and buildings, but form one LAN on a logical level.
Y
RTS/CTS threshold
Y
Security
Security algorithms
Security algorithms are used to provide authentication, cipher key generation, integrity and radio link privacy to users on mobile networks. The security algorithms supported are the ones that can be used with this product.
64-bit WEP,128-bit WEP,152-bit WEP,AES,HTTPS,SNMP,SSH,SSID,TKIP,WPA,WPA-PSK,WPA2,WPA2-PSK
MAC address filtering
Security access control method whereby the 48-bit address assigned to each network card is used to determine access to the network. MAC addresses are uniquely assigned to each card, so using MAC filtering on a network permits and denies network access to specific devices through the use of blacklists and whitelists.
Y
IP address filtering
Y
Service Set Identifier (SSID) features
SSID broadcast on/off
Number of SSID supported
1
IGMP snooping
Y
Auto Wireless Distribution System (WDS)
Y
Protocols
Universal Plug and Play (UPnP)
Y
DHCP client
Whether the product features a DHCP (Dynamic Host Configuration Protocol) to obtain IP addresses within a network.
Y
Management protocols
TDMA
Management features
Web-based management
Using a website/web application to manage something.
Y
Management platform
Pharos Control
Ports & interfaces
Ethernet LAN (RJ-45) ports
Number of Ethernet LAN (RJ-45) ports (connecting interfaces) in the device. Ethernet LAN (RJ-45) ports allow a computer to connect to the ethernet.
1
Internal RJ-45 ports quantity
1
DC-in jack
The socket/plug where the DC electricity supply connects to the device.
Y
Power
Power over Ethernet (PoE)
The device supports Power over Ethernet (PoE), which is one of several standardized or ad-hoc systems which pass electrical power along with data on Ethernet cabling. This allows a single cable to provide both data connection and electrical power to devices such as wireless access points or IP cameras.
Y
Input voltage
The voltage (V) which is required to power the product.
100 - 240 V
Input current
0.8 A
Input frequency
The frequency (Hz) which is required to power the product.
50/60 Hz
Output voltage
24 V
Output current
1 A
Power consumption (max)
The maximum amount of power used by the device.
10.8 W
Design
Product colour
The colour e.g. red, blue, green, black, white.
White
International Protection (IP) code
The IP code classifies and rates the degree of protection provided against the intrusion (including body parts such as hands and fingers), dust, accidental contact, and water by mechanical casings and electrical enclosures. It is published by the International Electrotechnical Commission (IEC). The digits (characteristic numerals) indicate conformity with the conditions summarized in the tables below. Where there is no protection rating with regard to one of the criteria, the digit is replaced with the letter X. an electrical socket rated IP22 is protected against insertion of fingers and will not be damaged or become unsafe during a specified test in which it is exposed to vertically or nearly vertically dripping water. Another example is the Sony Xperia Z Ultra, one of the first cellular phones to be IP-rated; it is rated at IP58 and marketed as "dust resistant" and can be "immersed in 1.5 meter of freshwater for up to 30 minutes".
IPX5
Reset button
Y
LED indicators
Power
Certification
- CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark - RoHS, IPX5
Internal
The product is built in.
N
Antenna
Antenna type
Type of antenna, also known an aerial, e.g. external, internal.
Internal
Antenna features
Integrated antenna
Antennas quantity
2
Antenna gain level (max)
Antenna gain is the measurement of an antenna's ability to amplify the incoming microwave signals in a particular direction, compared with the sensitivity of an isotropic antenna in any direction, or a dipole antenna in the equatorial direction.
12 dBi
Performance
Built-in processor
Whether or not a processor is built into the device.
Y
Flash memory
8 MB
Internal memory
The amount of memory, usually measured in bytes (e.g. MB, GB), which is installed in the system's hardware.
64 MB
Operational conditions
Operating relative humidity (H-H)
10 - 90%
Operating temperature (T-T)
The minimum and maximum temperatures at which the product can be safely operated.
-30 - 70 °C
Storage temperature (T-T)
The minimum and maximum temperatures at which the product can be safely stored.
-40 - 70 °C
Storage relative humidity (H-H)
5 - 95%
Weight & dimensions
Width
The measurement or extent of something from side to side.
110 mm
Depth
The distance from the front to the back of something.
57 mm
Height
The measurement of the product from head to foot or from base to top.
33.5 mm
Packaging data
AC adapter included
Y
Mounting kit
Y
Quick start guide
Instructions, either online, as a computer program or in paper form, to allow you to set up and start using the product quickly.
Y
