#html-body [data-pb-style=E0AD6PX]{justify-content:flex-start;display:flex;flex-direction:column;background-position:left top;background-size:cover;background-repeat:no-repeat;background-attachment:scroll}Teltonika | PR3PDNP0 | DIN Rail Power Supply Unit 20W | Suitable for RUT2xx, RUT9xx, RUT3xx, RUTXxx, TRB14x, TRB24x, TRB500, TSW010, TSW304?The PR3PDNP0 is designed to be used with the RUT240AU, RUT241, RUT300, RUT360, RUT950AU, RUT951, RUT955AU, RUT956, RUTX08, RUTX09, RUTX10, RUTX11, RUTX12, RUTX14, RUTX50, RUTXR1, TRB140AU, TRB141, TRB142AU, TRB145AU, TRB245AU, TRB255, TRB500, TSW010, TSW304.SPECIFICATIONS Single output power: 20 W Input voltage: 100 ? 240 VAC Input frequency: 50 / 60 Hz DC output voltage: 12 V DC output current:? 0 ? 1.67 A Output ripple and noise: 120 mVp-p Line regulation: ?1 % Load regulation: ?1 % Efficiency: c Adjustable range for DC voltage: ?1 % Maximum input inrush current: Cold start current 20 A / 115 VAC; 40 A / 230 VAC Overload protection: 105 % ~ 160 % cut off the output, automatic recovery Over voltage protection: 120 % ~ 140 % shut down O/P voltage, off/on cycle required for recovery Setup, rise, hold up time: 500 ms, 30 ms / 230 VAC at full load; 1000 ms, 30 ms / 115 VAC at full load Withstand voltage:? I/P-O/P: 1.5 kV; I/P-FG: 1.5 kV; O/P-FG: 0.5 kV 1 minute Isolation resistance: I/P-O/P I/P-FG O/P-FG: 500 VDC / 1000 M? Working temperature: ?10 ?C ~ +50 ?C Mounting options: 35 mm DIN Rail Dimensions: 22.5 x 90 x 100 mm Weight: 1900g Certification: EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, EN 55022:2010, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010/A1:2015 WARRANTY2-years limited warranty
